Product Summary

The TX2-24V is a new pin layout (LT type) added relay with broad lineup and AC 2000 V breakdown voltage.

Parametrics

TX2-24V absolute maximum ratings: (1)Switching Voltage: 220VDC Max; (2)Coil Type: Non Latching; (3)Coil Current: 28.1mA; (4)Coil Voltage: 5VDC; (5)Turn On Voltage (Max): 3.75 VDC; (6)Turn Off Voltage (Min): 0.5 VDC; (7)Features: Sealed Fully; (8)Mounting Type: Through Hole ; (9)Termination Style: PC Pin; (10)Packaging: Tube; (11)Contact Material: Silver Palladium (AgPd), Gold (Au); (12)Operate Time: 4ms; (13)Release Time: 4ms; (14)Coil Power: 140 mW; (15)Coil Resistance: 178 Ohms; (16)Operating Temperature: -40℃ ~ 85℃; (17)Lead Free Status: Lead Free.

Features

TX2-24V features: (1)2,000 V breakdown voltage between contact and coil; (2)Outstanding surge resistance; (3)Nominal operating power: High sensitivity of 140mW; (4)High contact capacity: 2 A 30 V DC 5. Compact size; (5)A range of surface-mount types is also available.

Diagrams

TX2-24V block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
TX2-24V
TX2-24V
Panasonic Electric Works
Low Signal Relays - PCB 2A 24VDC DPDT NON-LATCHING PCB
Data Sheet
0-1: $2.48
1-25: $2.37
25-50: $2.06
50-100: $1.79
TX2-24V-TH
TX2-24V-TH
Panasonic Electric Works
Low Signal Relays - PCB TX2 Relay (Thermostat - Gold sputtering
Data Sheet
0-1: $2.78
1-25: $2.56
25-50: $2.28
50-100: $1.93
TX2-24V-1
TX2-24V-1
Panasonic Electric Works
Low Signal Relays - PCB 2 Form C 2A 30VDC 24VDC
Data Sheet
0-1: $2.58
1-25: $2.36
25-50: $2.11
50-100: $1.79
