G2R-1-E-DC5V

power relay, High-sensitivity, 360 mW, high-capacity, 16 A, Double-winding latching type

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~1.20 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.00~1.20

PartNumber:: G2R-1-E-DC5V

Brand:: Omron Electronics LLC - OMRON | Pack: DIP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Helen's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-11-29

From Other Seller

Part Number:G2R-1-E-DC5V
US $1.00 - 1.20
iphone5 data cable

US $4.00 - 5.00 / Piece
(0) Remove
2DI240A-055

US $70.00 - 100.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The G2R-1-E-DC5V is a power relay for a variety of purposes with various models.

Parametrics

G2R-1-E-DC5V general specifications: (1)Contact resistance: 30 mΩ max. (high-capacity type: 100 mΩ max.) ; (2)Operate (set) time: 15 ms max. ; (3)Release (reset) time: AC: 10 ms max.; DC: 5 ms max. (w/built-in diode: 20 ms max.) ; (4)Max. operating frequency: Mechanical: 18,000 operations/hr; Electrical: 1,800 operations/hr (under rated load) ; (5)Insulation resistance: 1,000 MΩ min. (at 500 VDC) ; (6)Dielectric strength: 5,000 VAC, 50/60 Hz for 1 min between coil and contacts; 1,000 VAC, 50/60 Hz for 1 min between contacts of same polarity ; (7)Vibration resistance: Destruction: 10 to 55 to 10 Hz, 0.75-mm single amplitude (1.5-mm double amplitude); malfunction: 10 to 55 to 10 Hz, 0.75-mm single amplitude (1.5-mm double amplitude) ; (8)Shock resistance: Destruction: 1,000 m/s2; Malfunction: 200 m/s2 when energized; 100m/s2 when no energized ; (9)Endurance: Mechanical: AC coil: 10,000,000 operations min; DC coil: 20,000,000 operations min. (at 18,000 operations/hr); Electrical: 100,000 operations min. (at 1,800 operations/hr under rated load) ; (10)Ambient temperature: Operating: -40℃ to 70℃ (with no icing) ; (11)Ambient humidity: Operating: 5% to 85% ; (12)Weight: Approx. 17 g (plug-in terminal: approx. 20 g).

Features

G2R-1-E-DC5V features: (1)Conforms to VDE0435 (VDE approval: C250 insulation grade), UL508, CSA22.2, SEV, SEMKO; (2)Meets VDE0700 requirements for household products according to VDE0110; (3)Clearance and creepage distance: 8 mm / 8 m; (4)Models with CTI250 material available; (5)High-sensitivity (360 mW) and high-capacity (16 A) types available; (6)Double-winding latching type available; (7)Plug-in with test button and quick-connect terminals available; (8)Highly functional socket available.
