Product Summary

The G5NB-1A-E-DC5V is a Slim Compact Relay with 3 A Switching Capability and 10-kV Impulse Withstand Voltage. The applications of it are Water heaters, refrigerators, air conditioners, and small electric appliances.

Parametrics

G5NB-1A-E-DC5V absolute maximum ratings: (1)Rated voltage: 5V; (2)Rated current: 40.0 mA; (3)Coil resistance: 125 Ω; (4)Must operate voltage: 75% of rated voltage (max.); (5)Must release voltage: 10% of rated voltage (min.); (6)Max. voltage Standard: 180% of rated voltage (at 23℃); (7)High-capacity: 170% of rated voltage (at 23℃); (8)Power consumption: Approx. 200 mW.

Features

G5NB-1A-E-DC5V features: (1)Max size 20.5L x 7.2 W x 15.3 W mm; (2)Standard models switch up to 3 A; High-capacity models switch up to 5 A (AC loads only); (3)Low power consumption (200 mW); (4)Semi-sealed and sealed types available; (5)UL recognized / CSA certified. VDE Approved; (6)RoHS Compliant.

Diagrams

G5NB-1A-E-DC5V package dimensions
