Product Summary

The RY210005-1 is a Miniature Power PCB Relay. The applications of it are heating control, interface technology, domestic appliances, timers, temperature control.

Parametrics

RY210005-1 general specifications: (1)Ambient temperature range:-40 to +70℃; (2)Ambient temperature:max. 85℃ at 6A; (3)Operate- / release time:typ. 7 / 3 ms; (4)Bounce time NO / NC contact:2,5 / 4,5 ms; (5)Vibration resistance (function) NO / NC contact:20 / 5 g; (6)Shock resistance (function) NO / NC contact:20 / 5 g; (7)Shock resistance (destruction): 100 g.

Features

RY210005-1 features: (1)1 pole 8 A, 1 CO or 1 NO or 1 NC contact; (2)Low component height 12.3 mm; (3)5 kV / 8 mm coil-contact; (4)Reinforced insulation (protection class II); (5)Pinnings: 3.2 and 5 mm; (6)Sockets with PCB-type or screw-type terminals; (7)Especially suitable for resistive and inductive loads on NO and NC contacts; (8)Plastic materials according to IEC60335-1 (domestic appliances); (9)RoHS compliant (Directive 2002 / 95 / EC) as per product date code 0403.

Diagrams

RY210005-1 circuit diagram
