G2R-2-DC5V

power Relay, DIP, Various Models, 106 mA, 47 W, 0.53 W, High-sensitivity, high-capacity

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.95~1.20 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.95~1.20

PartNumber:: G2R-2-DC5V

Brand:: Omron Electronics LLC - OMRON | Pack: DIP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Helen's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-12-01

From Other Seller

Part Number:G2R-2-DC5V
US $0.95 - 1.20
ad7716ap

US $1.13 - 1.13 / Piece
(0) Remove
2DI240A-055

US $70.00 - 100.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The G2R-2-DC5V is a power Relay for a Variety of Purposes with Various Models.

Parametrics

G2R-2-DC5V absolute maximum ratings: (1)Rated current (50/60 Hz): 106 mA; (2)Coil resistance: 47 W; (3)Coil inductance (H) (ref. value), Armature OFF: 0.20; Armature ON: 0.39; (4)Must operate voltage: 70% max. of rated voltage; (5)Must release voltage: 15% min. of rated voltage; (6)Max. voltage: 170% of rated voltage (at 23?C); (7)Power consumption: Approx. 0.53 W.

Features

G2R-2-DC5V features: (1)Conforms to VDE0435 (VDE approval: C250 insulation grade),UL508, CSA22.2, SEV, SEMKO; (2)Meets VDE0700 requirements for household products according to VDE0110; (3)Clearance and creepage distance: 8 mm/8 m.; (4)Models with CTI250 material available; (5)High-sensitivity (360 mW) and high-capacity (16 A) types available; (6)Double-winding latching type available; (7)Plug-in with test button and quick-connect terminals available; (8)Highly functional socket available.
