Product Summary

The TX2-4.5V is a 2 A capacity relay with high surge voltage and high breakdown voltage.

Parametrics

TX2-4.5V absolute maximum ratings: (1)Temperature rise: Max. 50℃; (2)Operate time [Set time]:(at 20℃): Max. 4 ms (Approx. 2 ms); (3)Release time [Reset time] (at 20℃): Max. 4 ms (Approx. 1 ms); (4)Shock resistance, Functional: Min. 750 m/s; (5)Destructive: Min. 1,000 m/s2 {100 G}; (6)Vibration resistance, Functional: 196 m/s2 {20 G}, 10 to 55 Hz at double amplitude of 3.3 mm; Destructive: 294 m/s2 {30G}, 10 to 55 Hz at double amplitude of 5 mm; (7)Unit weight: Approx. 2 g.

Features

TX2-4.5V features: (1)Breakdown voltage between contacts and coil: 2,000 V; (2)Surge withstand between contacts and coil: 2,500 V; (3)High contact capacity: 2 A 30 V DC; (4)Surface-mount type available.

Diagrams

TX2-4.5V Dimensions

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
TX2-4.5V
TX2-4.5V
Panasonic Electric Works
Low Signal Relays - PCB 2A 4.5VDC DPDT NON-LATCHING PCB
Data Sheet
0-1: $2.00
1-25: $1.84
25-50: $1.63
50-100: $1.52
TX2-4.5V-1
TX2-4.5V-1
Panasonic Electric Works
Low Signal Relays - PCB 2 Form C 2A 30VDC 4.5VDC
Data Sheet
0-1: $2.18
1-25: $2.00
25-50: $1.79
50-100: $1.52
TX2-4.5V-TH
TX2-4.5V-TH
Panasonic Electric Works
Low Signal Relays - PCB TX Relay
Data Sheet
0-1: $2.54
1-25: $2.32
25-50: $2.08
50-100: $1.76
