Product Summary

The PA1A-24V is a slim power relay.

Parametrics

PA1A-24V absolute maximum ratings: (1)Max. operating speed: 20 cpm at rated load; (2)Initial insulation resistance: Min. 1,000 MΩ at 500 V DC; (3)Initial breakdown voltage, Between open contacts: 1,000 Vrms; Between contacts and coil: 2,000 Vrms; (4)Surge voltage between contacts and coil: 4,000 V; (5)Operate time: Approx. 6 ms; (6)Release time (at nominal voltage): Approx. 3 ms; (7)Temperature rise Max. 45 ℃ with nominal coil voltage across coil and at nominal switching capacity; (8)Shock resistance, Functional: Min. 147 m/s2 (15 G); Destructive: Min. 980 m/s2 (100 G); (9)Unit weight: Approx 3 g .15 oz.

Features

PA1A-24V features: (1)Slim size (width 5 mm .197 inch, height 12.5 mm .492 inch)permits higher density mounting; (2)Wide switching capacity: Control from 100mA 100 mV to 5 A 250 V AC, 30 V DC; (3)High sensitivity: 120 mW (Nominal) (5 to 18 V DC type); (4)High surge voltage (4000 V) and high breakdown voltage(2000 V); (5)Shock & vibration resistance (functional): Min. 147m/s2 (15 G); (6)SIL (single in line) terminal layout; (7)Reinforced according to IEC1131-2.

Diagrams

PA1A-24V dimensions

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
PA1A-24V
PA1A-24V
Panasonic Electric Works
General Purpose / Industrial Relays 5A 24VDC SPST-NO NON-LATCHING
Data Sheet
0-1: $4.82
1-25: $4.43
25-50: $3.94
50-100: $3.34
Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
PA1A-12V
PA1A-12V
Panasonic Electric Works
General Purpose / Industrial Relays 5A 12VDC SPST-NO NON-LATCHING
Data Sheet
0-1: $4.82
1-25: $4.43
25-50: $3.94
50-100: $3.34
PA1A-12V-Y1
PA1A-12V-Y1
Panasonic Electric Works
Relay Sockets & Hardware 1 Form A 12V 3A 250VAC 3A 30VDC
Data Sheet
0-1: $3.55
1-25: $3.18
25-50: $2.90
50-100: $2.47
PA1a-18V
PA1a-18V
Panasonic Electric Works
General Purpose / Industrial Relays 1 Form A 18V 3A 250VAC 3A 30VDC
Data Sheet
0-1: $5.02
1-25: $4.60
25-50: $4.10
50-100: $3.49
PA1A-24V
PA1A-24V
Panasonic Electric Works
General Purpose / Industrial Relays 5A 24VDC SPST-NO NON-LATCHING
Data Sheet
0-1: $4.82
1-25: $4.43
25-50: $3.94
50-100: $3.34
PA1A-5V
PA1A-5V
Panasonic Electric Works
General Purpose / Industrial Relays 5A 5VDC SPST-NO NON-LATCHING
Data Sheet
0-1: $4.81
1-25: $4.41
25-50: $3.94
50-100: $3.34
PA1A-5V-Y1
PA1A-5V-Y1
Panasonic Electric Works
Relay Sockets & Hardware 1 Form A 5V 3A 250VAC 3A 30VDC
Data Sheet
0-1: $3.55
1-25: $3.25
25-50: $2.90
50-100: $2.47
