Product Summary
Parametrics
Product Type Features:
Terminal Shape = Ring Tongue
Receptacle Style = Straight
Body Style = PIDG
Barrel Type = Closed Barrel
Wire/Cable Type = Regular Wire
Insulation = Yes
Insulation Support = Insulation Support
Insulation Diameter (mm [in]) = 3.81 [.150] Max.
Stud Diameter (mm [in]) = 4.17 [0.164]
Stud Size = 8 [M4]
Shape = RING-041
Heavy Duty = No
Material = Copper
Finish = Tin
Color = Blue
Insulation Material = Nylon
Electrical Characteristics:
Voltage (VAC) = 300
Termination Features:
Wire/Cable Size (CMA) = 2,050 鈥?5,180
Body Features:
Wire Range (mm [AWG]) = 1.25-2.00虏 [16-14]
Tongue Material Thickness (mm [in]) = 0.84 [0.033]
Industry Standards:
Government/Industry Qualification = No
RoHS/ELV Compliance = RoHS compliant, ELV compliant
Lead Free Solder Processes = Not relevant for lead free process
RoHS/ELV Compliance History = Always was RoHS compliant
Packaging Features:
Packaging Method = Loose Piece
Other:
Brand = AMP
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 320560 |
TE Connectivity / AMP |
Terminals RING TONGUE |
Data Sheet |
|
|
||||||||||||
