The TQ2SA-5V-Z is a low-profile surface-mount relay.
Parametrics
TQ2SA-5V-Z absolute maximum ratings: (1)Nominal switching capacity (resistive load): 2 A 30 V DC, 0.5 A 125 V AC; (2)Max. switching power (resistive load): 60 W, 62.5 VA; (3)Max. switching voltage: 220 V DC, 125 V AC; (4)Max. switching current: 2 A; (5)Min. switching capacity g1 10 mA 10 mV DC Ambient temperature: –40℃ to +85℃.
Features
TQ2SA-5V-Z features: (1)Low-profile: 6 mm.236 inch in height comforming to EIA standards (Tape height: max. 6.5 mm.256 inch ); (2)Tape and reel package is available as standard packing style; (3)Surge withstand between contacts and coil: 2,500 V; (4)Breakdown voltage between contacts and coil: 1,500 V; (5)High capacity: 2 A; (6)High sensitivity: 2 Form C; 140 mW power consumption (Single side stable type).
