Product Summary

The SDT-S-124DMR is a 10 Amp Miniature Power PC Board Relay. The applications of it are appliances, HVAC, cable TV, monitor display.

Parametrics

SDT-S-124DMR general specifications: (1)contact arrangement:1 Form A; (2)rated voltage:250VAC, 30VDC; (3)max. switching voltage:250VAC, 30VDC; (4)rated current:5 to 10A; (5)contact material:AgSnO2; (6)min. recommended contact load:100mA at 5VDC; (7)frequency of operation:360ops./h; (8)operate/release time max.:15/5ms.

Features

SDT-S-124DMR features: (1)10A contact rating; (2)UL TV-5 and TV-8 rating; (3)1 form A(NO) contact arrangement; (4)sensitive and standard coils available.

Diagrams

SDT-S-124DMR circuit diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
SDT-S-124DMR,000
SDT-S-124DMR,000


RELAY GEN PURPOSE SPST 10A 24V

Data Sheet

0-500: $0.58
Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
SDT-1204P
SDT-1204P

Other


Data Sheet

Negotiable
SDT-S-103LMR,000
SDT-S-103LMR,000


RELAY GEN PURPOSE SPST 10A 3V

Data Sheet

0-500: $0.57
SDT-S-105LMR,000
SDT-S-105LMR,000


RELAY GEN PURPOSE SPST 10A 5V

Data Sheet

0-1000: $0.46
SDT-S-105LMR2,000
SDT-S-105LMR2,000


RELAY GEN PURPOSE SPST 10A 5V

Data Sheet

0-1000: $0.50
SDT-S-106LMR,000
SDT-S-106LMR,000


RELAY GEN PURPOSE SPST 10A 6V

Data Sheet

0-500: $0.57
SDT-S-109DMR,000
SDT-S-109DMR,000


RELAY GEN PURPOSE SPST 10A 9V

Data Sheet

0-500: $0.57
