Product Summary

The DSP1-DC5V-F is a 5A small polarized power relay. The applications of it are Office and industrial electronic devices, printer, data recorder, Office equipment (copier, facsimile), Measuring instruments, NC machines, temperature controllers and programmable logic controllers.

Parametrics

DSP1-DC5V-F absolute maximum ratings: (1)Contact Rating (Current):5A ; (2)Switching Voltage:250VAC, 30VDC - Max ; (3)Coil Type:Non Latching ; (4)Coil Current:60mA ; (5)Coil Voltage:5VDC ; (6)Turn On Voltage (Max):4 VDC ; (7)Turn Off Voltage (Min):0.5 VDC ; (8)Mounting Type:Through Hole ; (9)Termination Style:PC Pin ; (10)Packaging:Bulk ; (11)Features:Sealed - Fully ; (12)Contact Material:Silver Tin Oxide (AgSnO) ; (13)Operate Time:10ms ; (14)Release Time:5ms ; (15)Operating Temperature:-40 to 65℃; (16)Coil Power:300 mW ; (17)Coil Resistance:83.3 Ohms ; (18)Lead Free Status:Lead Free ; (19)RoHS Status:RoHS Compliant.

Features

DSP1-DC5V-F features: (1)Compact with high contact rating; (2)High switching capability; (3)High sensitivity; (4)High breakdown voltage; (5)Latching types available; (6)Wide variation; (7)Sealed construction allows automatic washing; (8)Complies with safety standards; (9)Sockets are available.
